1

Three blocks A, B and C are lying on a smooth horizontal surface, as shown in the figure. A and B have equal masses, m while C has mass M, Block A is given an initial speed $$\upsilon $$ towards B due to which it collides with B perfectly inelastically. The combined mass collides with C, also perfectly inelastically $${5 \over 6}$$th of the initial kinetic energy is lost in whole process. What is value of M/m ?

A

5

B

2

C

4

D

3

As in elastic or in elastic clollision, momentum is conserved.

$$ \therefore $$ P_{i} = P_{f}

P_{i} = Initial momentum

P_{f} = Final Momentum

mv = (2m + m) V_{f}

$$ \Rightarrow $$ V_{f} = $${{mv} \over {2m + M}}$$

Here due to collision $${5 \over 6}$$th of kinetic energy is lost.

$$ \therefore $$ Remaining kinetic energy,

K_{f} = $${1 \over 6}$$ Ki

$$ \Rightarrow $$ $${1 \over 2}$$(2m + M) $$ \times $$ $${{{{\left( {mv} \right)}^2}} \over {{{\left( {2m + M} \right)}^2}}}$$ = $${1 \over 6} \times {1 \over 2}m{v^2}$$

$$ \Rightarrow $$ $${{{m^2}{v^2}} \over {2m + M}}$$ = $${1 \over 6}m{v^2}$$

$$ \Rightarrow $$ $${m \over {2m + M}}$$ = $${1 \over 6}$$

$$ \Rightarrow $$ 6m = 2m + M

$$ \Rightarrow $$ M = 4m

$$ \Rightarrow $$ $${M \over m}$$ = 4

$$ \therefore $$ P

P

P

mv = (2m + m) V

$$ \Rightarrow $$ V

Here due to collision $${5 \over 6}$$th of kinetic energy is lost.

$$ \therefore $$ Remaining kinetic energy,

K

$$ \Rightarrow $$ $${1 \over 2}$$(2m + M) $$ \times $$ $${{{{\left( {mv} \right)}^2}} \over {{{\left( {2m + M} \right)}^2}}}$$ = $${1 \over 6} \times {1 \over 2}m{v^2}$$

$$ \Rightarrow $$ $${{{m^2}{v^2}} \over {2m + M}}$$ = $${1 \over 6}m{v^2}$$

$$ \Rightarrow $$ $${m \over {2m + M}}$$ = $${1 \over 6}$$

$$ \Rightarrow $$ 6m = 2m + M

$$ \Rightarrow $$ M = 4m

$$ \Rightarrow $$ $${M \over m}$$ = 4

2

A force acts on a 2 kg object so that its position is given as a function of time as x = 3t^{2} + 5. What is the work done by this force in first 5 seconds ?

A

850 J

B

950 J

C

875 J

D

900 J

Displacement,

x = 3t^{2} + 5

$$ \therefore $$ v = $${{dx} \over {dt}} = 6t$$

At t = 0, velocity = 6 $$ \times $$ 0 = 0

at t = 5, velocity = 5 $$ \times $$ 6 = 30 m/s

we know from work energy theorem,

Work (W) = change in kinetic energy ($$\Delta $$K)

= $${1 \over 2}mv_F^2 - {1 \over 2}mv_i^2$$

= $${1 \over 2}$$ $$ \times $$ 2 $$ \times $$ (30)^{2} $$-$$ 0

= 900 J

x = 3t

$$ \therefore $$ v = $${{dx} \over {dt}} = 6t$$

At t = 0, velocity = 6 $$ \times $$ 0 = 0

at t = 5, velocity = 5 $$ \times $$ 6 = 30 m/s

we know from work energy theorem,

Work (W) = change in kinetic energy ($$\Delta $$K)

= $${1 \over 2}mv_F^2 - {1 \over 2}mv_i^2$$

= $${1 \over 2}$$ $$ \times $$ 2 $$ \times $$ (30)

= 900 J

3

A block of mass m is kept on a platform which starts from rest with constant acceleration g/2 upward, as shown in figure. Work done by normal reaction on block in time is -

A

$${{m{g^2}{t^2}} \over 8}$$

B

$${{3m{g^2}{t^2}} \over 8}$$

C

$$-$$ $${{m{g^2}{t^2}} \over 8}$$

D

0

N $$-$$ mg = $${{mg} \over 2}$$ $$ \Rightarrow $$ N = $${{3mg} \over 2}$$

The distance travelled by the system in time t is

S = ut + $${1 \over 2}a{t^2} = 0 + {1 \over 2}\left( {{g \over 2}} \right){t^2} = {1 \over 2}{g \over 2}{t^2}$$

Now, work done

W = N.S = $$\left( {{3 \over 2}mg} \right)\left( {{1 \over 2}{g \over 2}{t^2}} \right)$$

$$ \Rightarrow $$ W = $${{3m{g^2}{t^2}} \over 8}$$

The distance travelled by the system in time t is

S = ut + $${1 \over 2}a{t^2} = 0 + {1 \over 2}\left( {{g \over 2}} \right){t^2} = {1 \over 2}{g \over 2}{t^2}$$

Now, work done

W = N.S = $$\left( {{3 \over 2}mg} \right)\left( {{1 \over 2}{g \over 2}{t^2}} \right)$$

$$ \Rightarrow $$ W = $${{3m{g^2}{t^2}} \over 8}$$

4

A particle which is experiencing a force, given by $$\overrightarrow F = 3\widehat i - 12\widehat j,$$ undergoes a displacement of $$\overrightarrow d = 4\overrightarrow i $$ particle had a kinetic energy of 3 J at the beginning of the displacement, what is its kinetic energy at the end of the displacement ?

A

9 J

B

10 J

C

12 J

D

15 J

Work done = $$\overrightarrow F \cdot \overrightarrow d $$

$$=$$ 12 J

work energy theorem

w_{net} $$=$$ $$\Delta $$K.E.

12 $$=$$ K_{f} $$-$$ 3

K_{f} = 15 J

$$=$$ 12 J

work energy theorem

w

12 $$=$$ K

K
